SBA62


TECHNICAL CHARACTERISTICS Download PDF

Chassis: Self-supporting anti-corrosion Aluminium structure
Axles: fix, single, 9000 Kg capacity, 1st axle liftable Brakes: disc Ø 370 mm
Braking system: pneumatic with two lines according to ECE R13 with Electronic Braking System (EBS) and RSS
Suspensions: pneumatic type with electronic control
Wheels: disc 19.5 x 14.00 - M spigot
Tyres: 445/45R19.5 160 J single Accessories: 2 King Pin in accordance with EEC standards demountable from below; 24 t landing legs with two speed and rocking feet; spare wheel carrier; side guards; mudguards; wheel chock; tool box
Body: box unit for live stock transport with 2 or 3 or 4 loading deck; insulated and liftable roof; internal working lights and fan system
Rear loading bridge: hydraulically controlled, anti-slip, with incorporated side guards and working as barn doors if necessary
Electrohydraulic system: autonomous type with electro-pump and high capacity batteries, completed with automatic safety device in accordance with Machines Directive and Work Safety Institute
Drinking system: automatic type with nipples for pigs and water tank 400 l.
Ventilation system: autonomous with 15 side fans Ø 255 mm. Total max. flow 19500 m3/h
Partition gates: aluminium swinging or foldable type
Coupling: low deck tractor

OPTIONALS
  • Independent movement for loading floor
  • 3° axle self-steering (+200 Kg)
  • Positioning GPS system integrated with temperature and opening doors recording
